Swallow Raven 8x12 Greenhouse + 4ft Shed Combination

Quick Code: P172228
Greenhouse Size Diagram

Greenhouse with 4ft Shed Extension Dimensions:

A: Greenhouse width

2660mm (8′ 9″)

B: Greenhouse depth

5100mm (16′ 9″)

C: Ridge height

2660mm (8′ 9″)

D: Eaves height

1730mm (5′ 8″)

E & F: Door Size

1200mm (3′ 11″) x 1980mm (6′ 6″) (aperture)

Minimum Base Size

2660mm (8′ 9″) x 5100mm (16′ 9″)

Greenhouse with 6ft Shed Extension Dimensions:

A: Greenhouse width

2660mm (8′ 9″)

B: Greenhouse depth

5730mm (18′ 10″)

C: Ridge height

2660mm (8′ 9″)

D: Eaves height

1730mm (5′ 8″)

E & F: Door Size

1200mm (3′ 11″) x 1980mm (6′ 6″) (aperture)

Minimum Base Size

2660mm (8′ 9″) x 5730mm (18′ 10″)

Greenhouse with 8ft Shed Extension Dimensions:

A: Greenhouse width

2660mm (8′ 9″)

B: Greenhouse depth

6360mm (20′ 10″)

C: Ridge height

2660mm (8′ 9″)

D: Eaves height

1730mm (5′ 8″)

E & F: Door Size

1200mm (3′ 11″) x 1980mm (6′ 6″) (aperture)

Minimum Base Size

2660mm (8′ 9″) x 6360mm (20′ 10″)

Greenhouse with 10ft Shed Extension Dimensions:

A: Greenhouse width

2660mm (8′ 9″)

B: Greenhouse depth

6985mm (22′ 11″)

C: Ridge height

2660mm (8′ 9″)

D: Eaves height

1730mm (5′ 8″)

E & F: Door Size

1200mm (3′ 11″) x 1980mm (6′ 6″) (aperture)

Minimum Base Size

2660mm (8′ 9″) x 6985mm (22′ 11″)

Swallow Installation Access

Larks and Robins: The minimum access height required for installation

1727mm (5′ 8″)

Cygnet, Jay, and Kingfishers: The minimum access height required for installation, no access through a property.

2032mm (6′ 8″)

Mallard, Swan, Raven, Rook, Falcon, and Eagles: The minimum access height required for installation, no access through a property.

2672mm (8′ 9″)

Always use MM dimensions when planning and building your base: No right angle turns between the access point and installation site.

Please contact us if you have any questions regarding your base area or site.

Why is ThermoWood® the Best?

Thermowood Greenhouse

ThermoWood® is a special thermally modified timber developed in Finland. The timber is heated treated up to 215 °C to remove all excess moisture. This wood is well suited for outdoor applications where demanding weather conditions are the norm. The key performance features of ThermoWood® over Tanalised timber are:

Improved durability against decay
Resin removed
Improved dimensional stability
Consistent colouring throughout
Reduced equilibrium moisture content

The timber is used extensively throughout Scandinavia for all sorts of interior and exterior construction, cladding and decoration due to it’s good looks and superb resilience to harsh weather.

Oiled Finish as Standard

Oiled Panel

Oiling Wood serves as a protective and nourishing treatment, enhancing its natural beauty while preventing dryness, cracking, and decay. This simple yet effective process not only deepens the wood's colour and grain but also prolongs its lifespan, making it an essential practice for maintaining the durability and aesthetic appeal of wooden surfaces. Its also easy to maintain and reapply when needed.

Autovents as Standard

Greenhouse Roof Auto Vents

Swallow use high quality Bayliss XL Automatic roof vent openers as standard on every roof vent. Even when you're not around your greenhouse will be well ventilated.

Staging

Swallow Greenhouse Staging

Swallow include a length of slatted staging with all greenhouses that is 520mm wide and 745mm high.

Installation Included

Swallow Greenhouses are delivered and installed countrywide for free. You simply order your new greenhouse and it will be delivered and erected in your garden by a Swallow fitting team.

Damp Barrier

Swallow Greenhouse Damp Barrier

20mm black PVC section screwed to the bottom of the greenhouse stops damp rising into the timber.

sku:SR812S4

£7,083

Pay only 20% Deposit

£1417

FREE Installation!!

Qty

Check Delivery

Enter your Postcode below to check delivery

Delivery: Within 8-12 weeks*

Delivered and Installed within 8-12 weeks from the date that you confirm your base is ready for all finishes.

  • 2660mm (8ft 9") Wide Wooden Greenhouse - Wide access for wheelbarrows etc
  • Oiled ThermoWood Construction - Heat treated high performance timber.
  • 3mm Toughened Glazing - Safe, Strong and Family Friendly.
  • 4 Opening Roof Vents - For Ventilation.
  • 4 Bayliss XL Autovents - Automatically opens your roof vents.
  • Double Doors with Mortise Lock - Wide access and Security
  • Bottom Boards 12mm - Tongued and Grooved with stainless steel nails.
  • Glazing Grooves to hold glazing - Solid and Silicone Sealed.
  • Full length of Slatted Staging to one side - 520mm wide, 745mm high.
  • Shed floor as standard - Keep your items off the floor.
  • 762mm (2ft 6") Shed Door with Stainless Handle, Hinges and Lock - Wide access.
  • 2 full length shelves to one side of the shed Added Storage.
  • 20mm Black PVC Damp Barrier - Screwed to bottom for rising damp protection.
  • 5 Year Warranty - on frame and base.
  • Installation Included in Price - Just order and everything is done for you !

The 8ft x 12ft Swallow Raven Combi Shed Greenhouse offers the best of both worlds with a 4ft Shed and 12ft Greenhouse. Secure storage coupled with a large 12ft growing space. Looking for more storage then choose a 6ft, 8ft or 10ft shed extension. It`s a practical size, looks superb and is installed for FREE!

3mm Toughened Safety Glass is standard on all Swallow wooden Greenhouses and is held in special grooves within the frame and then sealed in place with quality silicone. Inward opening doors with mortise locks are also standard.

Each roof vent is supplied with a Bayliss XL autovent to automatically open the roof vent when you`re not around to stop over heating. You also get a Shed Floor and a full length of slatted staging down one side of the greenhouse for working on and storing your plants.

The Swallow Raven Combi is the finest 8ft wide wooden greenhouse shed combination available today and when you consider it has a 5 YEAR WARRANTY and free installation it`s not hard to understand why we rate Swallow wooden greenhouses so very highly.

Options: Click options to add them to your order then click "Buy Now"

1: Change your Shed size

4ft Shed extension with floor
4ft Shed extension with floor

A compact 4ft 3" Shed extension giving a total building length of 16ft 9"

+ £0
6ft Shed Combination with floor
6ft Shed Combination with floor

Add a larger 6ft shed to your greenhouse to give a total length of 18ft 10"

+ £410
8ft Shed Extension with floor
8ft Shed Extension with floor

Add a larger 8ft shed to your greenhouse to give a total length of 20ft 10"

+ £821

2: Painted Finish 4ft

The paint is applied in Swallow’s specialist spray booth with an opaque protective top coat with a flexible microporous film. This paint finish is resistant to bacterial mold and UV sun damage. Custom colours are available for an additional cost and will be colour matched to your choice using Swallow’s in-house specialist paint.

Oiled Finish
Oiled Finish

+ £0
Lily White
Lily White

+ £966
Bracken
Bracken

+ £966
Olive
Olive

+ £966
Midnight
Midnight

+ £966
Black
Black

+ £966
Stone
Stone

+ £966
Summer Green
Summer Green

+ £966
Cloud Grey
Cloud Grey

+ £966
Slate
Slate

+ £966
Robin’s Egg Blue
Robin’s Egg Blue

+ £1,023

3: Painted Finish 6ft

The paint is applied in Swallow’s specialist spray booth with an opaque protective top coat with a flexible microporous film. This paint finish is resistant to bacterial mold and UV sun damage. Custom colours are available for an additional cost and will be colour matched to your choice using Swallow’s in-house specialist paint.

Oiled Finish
Oiled Finish

+ £0
Lily White
Lily White

+ £1,023
Bracken
Bracken

+ £1,023
Olive
Olive

+ £1,023
Midnight
Midnight

+ £1,023
Black
Black

+ £1,023
Stone
Stone

+ £1,023
Summer Green
Summer Green

+ £1,023
Cloud Grey
Cloud Grey

+ £1,023
Slate
Slate

+ £1,023
Robin’s Egg Blue
Robin’s Egg Blue

+ £1,703

4: Painted Finish 8ft

The paint is applied in Swallow’s specialist spray booth with an opaque protective top coat with a flexible microporous film. This paint finish is resistant to bacterial mold and UV sun damage. Custom colours are available for an additional cost and will be colour matched to your choice using Swallow’s in-house specialist paint.

Oiled Finish
Oiled Finish

+ £0
Lily White
Lily White

+ £1,078
Bracken
Bracken

+ £1,078
Olive
Olive

+ £1,078
Midnight
Midnight

+ £1,078
Black
Black

+ £1,078
Stone
Stone

+ £1,078
Summer Green
Summer Green

+ £1,078
Cloud Grey
Cloud Grey

+ £1,078
Slate
Slate

+ £1,078
Robin’s Egg Blue
Robin’s Egg Blue

+ £1,078

5: Select your Size

6: Useful Extras

High Level Shelf Oiled Finish
High Level Shelf Oiled Finish

Add a 250mm wide high level shelf for extra storage of plants, seeds and tools etc

+ £131
Qty 1
Extra Side of Staging Oiled Finish
Extra Side of Staging Oiled Finish

Add another side of staging to the other side of your greenhouse.

+ £263

7: Rainwater Systems

White Rainwater System
White Rainwater System

Add a White Rainwater System to collect and reuse all of that lovely rainwater. Rainwater is after all the best water for your plants.

+ £386
Black Rainwater System
Black Rainwater System

Add a Black Rainwater System to collect and reuse all of that lovely rainwater. Rainwater is after all the best water for your plants.

+ £386

8: Additional Shed Options

Fixed Shed Window
Fixed Shed Window

Let some light into your shed

+ £82
Qty 1
Opening Shed Window
Opening Shed Window

Add circulation as well as light to your shed.

+ £169
Qty 1
External Shed Door
External Shed Door

Add a door at the rear of your shed extension.

+ £371

9: Useful Greenhouse Extras

Greenhouse Side Vent Oiled Finish
Greenhouse Side Vent Oiled Finish

This side vent opening window will give your greenhouse good ventilation by letting cool air flow in to regulate the temperature and humidity inside, without having to leave the door open.

+ £135
Qty 1
Swallow Sparrow Cold Frame Oiled
Swallow Sparrow Cold Frame Oiled

Add a Sparrow Coldframe to give even more room for seedlings and plants. Dimensions: 4ft 5" X 3ft 4"

+ £500
Qty 1
Swallow Wren Frame Oiled Finish
Swallow Wren Frame Oiled Finish

4ft 5" x 2ft 1" Cold Frame with toughened Safety Glass.

+ £425
Qty 1
Bench with Shelf Oiled Finish
Bench with Shelf Oiled Finish

Add a useful work bench with lower shelf that you can move around the greenhouse to suit you. Dimensions: 1200mm x 540mm

+ £326
Qty 1
Black Ornate Door Handle
Black Ornate Door Handle

Add a black wrought iron ornate door handle. Price is for one handle per door

+ £30
Qty 1
