Elite Edge 4x16 Pent Roof Greenhouse - Toughened Glazing

Quick Code: P172771
Greenhouse Size Diagram

Greenhouse Dimensions

A: Greenhouse width

1355mm (4′ 5″)

B: Greenhouse depth

5059mm (16′ 7″)

C: Ridge height

2410mm (7′ 10″)

D: Eaves height

1890mm (6′ 2″)

E & F: Door Size

1150mm (3′ 9″) x 1910mm (6′ 3″) (aperture)

Minimum Base Size

1355mm (4′ 5″) x 5059mm (16′ 7″)

Roof Dimensions

1552mm (5′ 1″) x 5059mm (16′ 7″)

Diamond Shelving and Staging - Optional

Elite Integral Gutters

The superb Diamond shelving and staging is designed specifically to fit into Elite greenhouses. It’s rigid and hard wearing and built to last. The Staging is supported by cantilever bracing so there are no legs to get in the way. This leaves space underneath to grow plants, store pots and makes using the greenhouse for wheelchair users completely practical. Both staging and shelving can be colour coded to match your new greenhouse.

Integral Gutters

Elite Integral Gutters

You’ll find proper gutters on Elite greenhouses rather than narrow channels. These are more effective at gathering up rainwater for your water butt and less likely to get blocked up with leaves.

sku:ELI-EDGE4-16-AL-TG

£2,359

Qty

Check Delivery

Enter your Postcode below to check delivery

Mill finish All Glazing 4-5 weeks,

Powder coated Compact, Streamline, Craftsman, High Eave and Belmont 8-10 weeks,

Other Powder Coated Models: 10-14 weeks

*For North of Glasgow, NI, and offshore, please call for a quote.

  • New Pent Roof Titan Style for 2019
  • 1355mm (4ft 3") Wide Aluminium Greenhouse - Practical size.
  • 7ft 9" Ridge height - High ridge for maximum growing height.
  • 4mm Toughened Glazing - Full Length Grade A EN12150 Standard.
  • Bar Capping as Standard - For extra glazing security.
  • Unique Core Vect Block Bar construction - Ultimate strength throughout.
  • High Tensile Nuts & Bolts - Nearly 3 times stronger than standard greenhouse fixings.
  • Silver Aluminum Frame - Rust and maintenance free.
  • Double Sliding Doors - Low Threshold.
  • No Base Needed!! Includes Flat sills.
  • 2 Opening Roof Vents Allows hot air to escape for Ventilation.
  • 1 Louvre Window Vent - Allows in cool air to moderate humidity.
  • 10 Year Warranty On aluminium frame and optional base.
  • Choice of door position, Please select from the options below

The NEW 4x16 Elite Edge Pent Roof Greenhouse is a completely reworked design of current greenhouse design. The extra high roof and eaves lend themselves to todays modern home growers.

The Elite Edge 4ft x 16ft pent greenhouse will give you plenty of space to bring on seedlings and grow salad, herbs and vegetables all year round as well as being a pleasant place to relax. The door on the Edge is fully lockable and features Elites low threshold cambered cill so you have no trips hazards!!.

Elite 4mm toughened safety glass gives you peace of mind where children and pets are present and safety is top of the list. Toughened glass simply granulates if broken removing any danger of injury from shards of glass. At Greenhouse Stores we recommend toughened glass for use in areas with high winds and harsher weather as it is heavier and is best suited to UK weather.

This Edge 400 4 x 16 has 2 opening roof vent and 1 louvre window vent for ventilation, smooth double sliding doors and integral gutters to collect rain water.

1: Select your Size

2: Greenhouse Installation by a certified greenhouse installer

Please Note: installation can only be carried out using the Optional Base Plinth (if available) onto a flat level surface such as slabs, concrete or decking that is to the Minimum base size stated in the dimensions diagram. Installation is for the Greenhouse, Ventilation and Downpipes only. The fitting of any additional accessories (shelving, staging etc) is not included. No groundworks are included.

Greenhouse Installation

We are currently able to offer installation in the following postcodes:

Your Greenhouse will be delivered and installed on the same day, this can add 2-4 weeks to the standard delivery time.

+ £835

3: Greenhouse Colour

Adding a custom powder coated finish to your new Elite greenhouse will increase the delivery time up to 8 weeks.

Plain  Finish
Plain Finish
+ £0
Green Powder Coating
Green Powder Coating
+ £941
Olive Powder Coating
Olive Powder Coating
+ £1,032
Black Powder Coating
Black Powder Coating
+ £1,032
Grey Powder Coating
Grey Powder Coating
+ £1,032
Navy Powder Coating
Navy Powder Coating
+ £1,032
White Powder Coating
White Powder Coating
+ £1,032
Brown Powder Coating
Brown Powder Coating
+ £1,032
Berry Powder Coating
Berry Powder Coating
+ £1,032
Stone Powder Coating
Stone Powder Coating
+ £1,032
Mocha Powder Coating
Mocha Powder Coating
+ £1,032

4: Bar Capping-Choose your colour

Bar Capping fits over the wire clips that hold your glass in the greenhouse frame. Not only does bar capping look good, it also makes your greenhouse very easy to keep clean. Bar Capping will also help to make your greenhouse more wind resistant by cutting out reverberation and glass movement in windy conditions.

Colour matched to your frame
Colour matched to your frame
+ £0
Green Bar Capping
Green Bar Capping
Olive Bar Capping
Olive Bar Capping
Black Bar Capping
Black Bar Capping
Grey Bar Capping
Grey Bar Capping
Navy Bar Capping
Navy Bar Capping
White Bar Capping
White Bar Capping
Brown Bar Capping
Brown Bar Capping
Berry Bar Capping
Berry Bar Capping
Stone Bar Capping
Stone Bar Capping
Mocha Bar Capping
Mocha Bar Capping

5: Staging and Shelving

You can configure your shelving and staging to make an "L" or "U" shaped run to suit your needs.

4ft long 5 Slat Staging Recommended
4ft long 5 Slat Staging
+ £92
Qty 1
16ft long 5 Slat Staging
16ft long 5 Slat Staging
+ £316
4ft long 2 Slat Shelving Recommended
4ft long 2 Slat Shelving
+ £44
Qty 1
16ft long 2 Slat Shelving
16ft long 2 Slat Shelving
+ £151
Qty 1

6: Staging and Shelving

You can configure your shelving and staging to make an "L" or "U" shaped run to suit your needs.

4ft long 5 Slat Colour Coded Staging
4ft long 5 Slat Colour Coded Staging
+ £151
Qty 1
16ft long 5 Slat Colour Coded Staging
16ft long 5 Slat Colour Coded Staging
+ £548
4ft long 2 Slat Colour Coded Shelving
4ft long 2 Slat Colour Coded Shelving
+ £76
Qty 1
16ft long 2 Slat Colour Coded Shelving
16ft long 2 Slat Colour Coded Shelving
+ £266

7: Ventilation and extras

Louvre Vent Recommended
Louvre Vent
+ £83
Qty 1
Colour Coded Louvre Vent
Colour Coded Louvre Vent
+ £150
Qty 1
Automatic Louvre Vent Opener
Automatic Louvre Vent Opener
+ £54
Qty 1
Standard rainwater kit
Standard rainwater kit
100 Litre Water Butt with Stand
100 Litre Water Butt with Stand
+ £67
Qty 1

8: Modular Staging

Elite 2 Tier Modular Staging
Elite 2 Tier Modular Staging
Elite 3 Tier Modular Staging
Elite 3 Tier Modular Staging
+ £102
Qty 1

9: Elite Options

Elite Digital Thermometer
Elite Digital Thermometer
+ £28
Qty 1
Tying Eyes (pack of 6)
Tying Eyes (pack of 6)
+ £13
Qty 1
Elite Potting Bench
Elite Potting Bench
+ £133
Qty 1
5 Tier Seed Tray Frame
5 Tier Seed Tray Frame
+ £178
Qty 1
3 Tier Seed Tray Frame
3 Tier Seed Tray Frame
+ £61
Qty 1
Elite Big Drippa Irrigation System
Elite Big Drippa Irrigation System
+ £44
Qty 1

10: Elite Raised Planters

Why not add an Elite Raised Planter to match your greenhouse? Made from the same high quality aluminium as your greenhouse and available in the great range of colours.

Elite Roots and Shoots 2x2 Raised Bed Alloy Finish
Elite Roots and Shoots 2x2 Raised Bed Alloy Finish
+ £110
Elite Roots and Shoots 2x2 Raised Bed Colour Matched
Elite Roots and Shoots 2x2 Raised Bed Colour Matched
+ £180
Elite Roots and Shoots 2x4 Raised Bed Alloy Finish
Elite Roots and Shoots 2x4 Raised Bed Alloy Finish
+ £155
Elite Roots and Shoots 2x4 Raised Bed Colour Matched
Elite Roots and Shoots 2x4 Raised Bed Colour Matched
+ £250
Elite Roots and Shoots 2x6 Raised Bed Alloy Finish
Elite Roots and Shoots 2x6 Raised Bed Alloy Finish
+ £199
Elite Roots and Shoots 2x4 Raised Bed Colour Matched
Elite Roots and Shoots 2x4 Raised Bed Colour Matched
+ £325
