ACD 5x12 P05 Piccolo Urban Greenhouse – RAL Colour

At a glance

  • 5ft 2" wide x 12ft 2" deep
  • Aluminium frame with a RAL colour finish
  • 1590mm wide x 3710mm deep
  • 1790mm eaves; 2210mm ridge
  • 4mm clear toughened safety glass roof
  • 4mm clear safety glass sides
  • One roof vent and single sliding door
  • Double-chamber self-supporting aluminium base and stainless steel fixings
  • 12-year structure warranty; 2-year coating warranty
  • Exact RAL code must be specified when ordering
  • Black RAL9005 is supplied as a separate Blackline version
  • Photographs show optional accessories, furnishings or planting, which are not included.
  • Main image illustrates RAL 5024 Pastel blue. Supplied in your chosen colour; screen colours may vary.
  • Tubular ridge beam and strengthened glazing bars
  • External gutters and internal condensation drainage
  • Rubber glazing seals hold glass firmly

Quick Code: P176556

Greenhouse Size Diagram

Greenhouse Dimensions

A: Greenhouse width

1590mm (5′ 2″)

B: Greenhouse depth

3710mm (12′ 2″)

C: Ridge height

2210mm (7′ 3″)

D: Eaves height

1790mm (5′ 10″)

Made in Belgium

Black Friday: up to £50 off

Discount applied automatically in the basket. No code to type. Ends 30 November 2026.

Discount already applied to price

Customise your Greenhouse

ACD 5x12 P05 Piccolo Urban Greenhouse – RAL ColourChoose your size, glazing and colour

Choose your frame finish

Custom powder coating is included in the displayed base price. Choose one colour. Screen swatches are approximate, so check a physical RAL sample.

Anthracite grey RAL 7016
+ £0

Custom powder-coated frame finish

Reed green RAL 6013
+ £0

Custom powder-coated frame finish

Olive green RAL 6003
+ £0

Custom powder-coated frame finish

Fir green RAL 6009
+ £0

Custom powder-coated frame finish

Quartz grey RAL 7039
+ £0

Custom powder-coated frame finish

Purple red RAL 3004
+ £0

Custom powder-coated frame finish

Carmine red RAL 3002
+ £0

Custom powder-coated frame finish

Pure white RAL 9010
+ £0

Custom powder-coated frame finish

Pale green RAL 6021
+ £0

Custom powder-coated frame finish

Black grey RAL 7021
+ £0

Custom powder-coated frame finish

Pastel blue RAL 5024
+ £0

Custom powder-coated frame finish

Signal red RAL 3001
+ £0

Custom powder-coated frame finish

Choose your frame finish information

Custom powder coating is included in the displayed base price. Choose one colour. Screen swatches are approximate, so check a physical RAL sample.

Anthracite grey - RAL 7016 - £0.00
Anthracite grey - RAL 7016

Custom powder-coated frame finish


Reed green - RAL 6013 - £0.00
Reed green - RAL 6013

Custom powder-coated frame finish


Olive green - RAL 6003 - £0.00
Olive green - RAL 6003

Custom powder-coated frame finish


Fir green - RAL 6009 - £0.00
Fir green - RAL 6009

Custom powder-coated frame finish


Quartz grey - RAL 7039 - £0.00
Quartz grey - RAL 7039

Custom powder-coated frame finish


Purple red - RAL 3004 - £0.00
Purple red - RAL 3004

Custom powder-coated frame finish


Carmine red - RAL 3002 - £0.00
Carmine red - RAL 3002

Custom powder-coated frame finish


Pure white - RAL 9010 - £0.00
Pure white - RAL 9010

Custom powder-coated frame finish


Pale green - RAL 6021 - £0.00
Pale green - RAL 6021

Custom powder-coated frame finish


Black grey - RAL 7021 - £0.00
Black grey - RAL 7021

Custom powder-coated frame finish


Pastel blue - RAL 5024 - £0.00
Pastel blue - RAL 5024

Custom powder-coated frame finish


Signal red - RAL 3001 - £0.00
Signal red - RAL 3001

Custom powder-coated frame finish


Add Ventilation?

Automatic wax-operated roof vent opener
+ £49

This wax-operated opener responds to temperature and opens the greenhouse roof vent without electricity.

Ventilation information

Automatic wax-operated roof vent opener - £49.00
Automatic wax-operated roof vent opener

This wax-operated opener responds to temperature and opens the greenhouse roof vent without electricity.


Add Shelving and Tables?

Matching aluminium shelves (pair)
+ £99

860 x 150mm each

Matching shelf with PVC inlay
+ £119

2250 x 320mm

Matching staging with PVC inlay
+ £158

2250 x 520mm

Matching sowing table
+ £198

2170 x 420mm

RAL-colour double shelf
+ £99

810 x 100 x 30mm

Shelving and Tables information

Matching aluminium shelves (pair) - £99.00
Matching aluminium shelves (pair)

860 x 150mm each


Matching shelf with PVC inlay - £119.00
Matching shelf with PVC inlay

2250 x 320mm


Matching staging with PVC inlay - £158.00
Matching staging with PVC inlay

2250 x 520mm


Matching sowing table - £198.00
Matching sowing table

2170 x 420mm


RAL-colour double shelf - £99.00
RAL-colour double shelf

810 x 100 x 30mm


Add Growing & Watering Accessories?

Greenhouse starter pack
+ £79

Includes two sowing trays, 10 tomato hooks, 10 plant guides, a drip kit and a thermometer.

Rainwater collection downpipes
+ £138

A pair of black aluminium downpipes, each 1650mm long and 40mm in diameter.

Growing & Watering Accessories information

Greenhouse starter pack - £79.00
Greenhouse starter pack

Includes two sowing trays, 10 tomato hooks, 10 plant guides, a drip kit and a thermometer.


Rainwater collection downpipes - £138.00
Rainwater collection downpipes

A pair of black aluminium downpipes, each 1650mm long and 40mm in diameter.


Add Access ramps?

Pair of aluminium access ramps
+ £139

Two short, individual aluminium ramps make it easier to move items over the base at your greenhouse entrance.

Access ramps information

Pair of aluminium access ramps - £139.00
Pair of aluminium access ramps

Two short, individual aluminium ramps make it easier to move items over the base at your greenhouse entrance.


Made in Belgium, the ACD 5x12 P05 Piccolo Urban Greenhouse comes in your chosen RAL finish, included in the price. Its narrow footprint leaves more garden width available while providing useful growing space along its length.

Strengthened aluminium profiles and a closed tubular ridge beam create a strong frame. A self-supporting double-chamber base completes the structure. There is a 12-year structure warranty and a two-year coating warranty.

Clear 4 mm toughened safety glass covers both roof and sides, so sunlight enters directly throughout. The single sliding door opens without swinging into the garden. One roof vent helps you ventilate the greenhouse during warmer weather.

Main image illustrates RAL 5024 Pastel blue. Supplied in your chosen colour; screen colours may vary.

  • Aluminium frame with a RAL colour finish
  • 1590mm wide x 3710mm deep
  • 1790mm eaves; 2210mm ridge
  • 4mm clear toughened safety glass roof
  • 4mm clear safety glass sides
  • One roof vent and single sliding door
  • Self-supporting base and stainless steel fixings
  • 12-year structure warranty; 2-year coating warranty
  • Exact RAL code required when ordering; Black RAL9005 is supplied as a separate Blackline version
  • Double-chamber self-supporting aluminium base
  • Tubular ridge beam and strengthened glazing bars
  • External gutters and internal condensation drainage
  • Rubber glazing seals hold glass firmly

ACD delivery is available only in supported postcode areas. Enter your delivery postcode to check. Delivery is unavailable in all other areas, where online ordering is not possible.

Greenhouse Size Diagram

Greenhouse Dimensions

A: Greenhouse width

1590mm (5′ 2″)

B: Greenhouse depth

3710mm (12′ 2″)

C: Ridge height

2210mm (7′ 3″)

D: Eaves height

1790mm (5′ 10″)

Made in Belgium

Clear toughened glass
Clear toughened glass

Urban Piccolo has clear 4mm toughened safety glass in both the roof and sides. Polished glass edges give the glazing a neat, considered finish.

Aluminium box corner profiles
Aluminium box corner profiles

Substantial hollow aluminium corner profiles support the greenhouse frame. Their box section provides strength at the corners within this Belgian-engineered frame.

Tubular aluminium ridge beam
Tubular aluminium ridge beam

The aluminium ridge beam has a fully enclosed tubular profile. This closed section gives strength along the top of the greenhouse roof.

Box-section aluminium glazing bars
Box-section aluminium glazing bars

Box-section aluminium glazing bars support the glass and resist twisting. Slots in the profiles provide fixing points for shelving or staging.

Corner and ridge reinforcement plates
Corner and ridge reinforcement plates

Extra reinforcement plates connect the roof and sidewalls at the corners and ridge. They strengthen these joints against wind and snow forces.

Diagonal greenhouse draw bars
Diagonal greenhouse draw bars

Diagonal draw bars are fixed at secure points within the frame. They help maintain the greenhouse's strength and alignment in windy conditions.

Self-supporting aluminium base
Self-supporting aluminium base

The included self-supporting aluminium base means you do not need a separate perimeter base. We recommend basic levelling of the ground before fitting. The supplied corner anchors must be set in concrete to secure the greenhouse.

Stainless steel nuts and bolts
Stainless steel nuts and bolts

Stainless steel nuts and bolts secure the frame throughout the greenhouse. Their corrosion resistance helps keep these frame fixings in good condition.

Rainwater and condensation channels
Rainwater and condensation channels

The gutter profile has a large external gutter for roof rainwater. A wide internal channel collects condensation within the same profile.

Rubber glazing profile seals
Rubber glazing profile seals

Rubber glazing seals fit into the aluminium profiles and hold the glass firmly. They also help keep rain and draughts outside the greenhouse.

Manual roof vent stay
Manual roof vent stay

The roof vent has a manual stay and storm protection. Opening the vent lets warm air escape and controls airflow on warmer days.

ACD greenhouse structure warranty
ACD greenhouse structure warranty

ACD has made greenhouses in Belgium since 1986. The structure has a 12-year warranty. Glazing and accessories are excluded.

TÜV NORD production controls
TÜV NORD production controls

ACD’s manufacturing processes are checked by TÜV NORD under the EN 1090-1 standard. Regular inspections help ensure consistent production quality.

Quick tour of ACD greenhouses

Take a quick look at the greenhouse construction in the tour video. Clear assembly instructions and videos are available.
